How does the brain work?

86 billion neurons, 100 trillion connections and about 20 watts. The cerebrum's two hemispheres each have frontal, parietal, temporal and occipital lobes, wrapped in a folded cortex only 2 to 4 mm thick. Under the back sits the cerebellum, and the brainstem joins it all to the spinal cord.

86 billion neurons, 100 trillion connections and about 20 watts. Take a 3D brain apart, fire a neuron, light up the areas you use to speak, and watch memories move while you sleep.

BrainClearOpened 10 Aug 202615 min to playFree · no sign-up

In 60 seconds

  1. Two halves, four lobes, one busy core

    The cerebrum's two hemispheres each have frontal, parietal, temporal and occipital lobes, wrapped in a folded cortex only 2 to 4 mm thick. Under the back sits the cerebellum, and the brainstem joins it all to the spinal cord. Deep inside are the thalamus, hippocampus, amygdala and basal ganglia.

  2. Neurons fire all-or-nothing spikes

    A neuron rests at about −70 mV. When its inputs push it past about −55 mV, sodium rushes in and it fires a 1 to 2 ms spike to about +35 mV. A stronger push makes more spikes, not bigger ones. Myelin makes spikes jump along the axon at up to about 120 m/s.

  3. Synapses turn sparks into chemicals

    At a synapse, the spike lets calcium in, vesicles spill neurotransmitter across a 20 nm gap, and receptors on the next cell open. Glutamate says go, GABA says stop. Many small inputs must add up to fire the next cell, and learning strengthens the synapses that are used together.

  4. Areas have jobs, but you use all of it

    Vision is at the back, hearing on the temporal lobe, movement and touch on strips either side of the central sulcus, with huge areas for hands and lips. Each side controls the opposite side of the body. The 10% myth and left-brain or right-brain personalities are myths: scans show the whole brain at work.

  5. Memories are sorted by day and filed by night

    The hippocampus tags new experiences, as the patient H.M. showed in 1953. Sleep runs in about 90-minute cycles, and during deep sleep the hippocampus replays the day to the cortex for long-term storage.

  6. A hungry organ that needs its blood

    At about 2% of body weight, the brain uses about 20% of the body's energy, about 20 W. A blocked artery, a stroke, can cost about 1.9 million neurons a minute, so learn BE FAST and call for help. For any worry about your own health, see a doctor.

The history

8,500 years from holes in skulls to a count of 86 billion neurons.

Read the full history
  1. 6500 BCEStone Age surgeons open the skull
  2. 400 BCEThe brain is the seat of the mind
  3. 1791Frog legs twitch with electricity
  4. 1953H.M. and the making of memory
  5. 1924The first human brain waves
  6. 1990Watching thought through blood

The full explanation

BrainClear, chapter by chapter

Chapter 1

Inside the human brain

Two wrinkled halves, four lobes each, and a busy core.

Your brain weighs about 1.3 to 1.4 kg, roughly as much as a small pineapple, and it is soft, about like firm tofu. The biggest part is the cerebrum: two halves, the left and right hemispheres, split by a deep groove down the middle. We are looking at the patient’s left side, with the forehead on your left.

Each hemisphere has four lobes. The frontal lobe plans and decides, the parietal lobe feels touch and knows where you are, the temporal lobe hears and helps you remember, and the occipital lobe at the back sees. The central sulcus separates frontal from parietal, and the lateral fissure tucks the temporal lobe underneath.

The surface is folded into ridges, gyri, and grooves, sulci. The outer layer, the cortex, is grey matter only 2 to 4 mm thick. Folding packs a sheet about the size of a large pillowcase into your skull. Under it lies white matter: billions of wires wrapped in fatty insulation.

Under the back sits the cerebellum (“little brain”), which keeps you balanced. The brainstem (midbrain, pons and medulla) runs your breathing and heartbeat and joins the spinal cord. Deep inside, turn on X-ray to find the thalamus, hypothalamus, hippocampus, amygdala, basal ganglia, the corpus callosum bridge, and fluid-filled ventricles.

Try “The map of parts” in the interactive model →

Chapter 2

A neuron fires

Tiny batteries, a trigger point, and a spike that races down a wire.

Your brain has about 86 billion neurons, nerve cells that talk with electricity and chemicals. A neuron has branching dendrites that collect messages, a cell body (soma) that adds them up, and one long axon that sends the answer, sometimes over a metre, to its axon terminals.

At rest, the inside of a neuron is about −70 mV compared with the outside, like a tiny battery. Pumps keep extra sodium (Na⁺) outside and potassium (K⁺) inside. When inputs nudge the voltage up to the threshold, about −55 mV, sodium gates snap open, Na⁺ floods in and the voltage shoots to about +35 mV. Then potassium gates open, K⁺ flows out, and the cell resets. That 1 to 2 millisecond blip is an action potential, or spike. For how voltage and current work, see OhmsLawClear.

Spikes are all-or-nothing: a weak push that misses threshold does nothing, and a strong push gives the same-sized spike. So how does a neuron say “strong”? It fires more often. That is rate coding.

Many axons are wrapped in myelin, a fatty insulation with small gaps called nodes of Ranvier. The spike jumps from node to node (saltatory conduction), reaching up to about 120 m/s. Bare axons manage about 1 m/s. In multiple sclerosis, the immune system damages myelin, which is why signals slow or fail.

Try “Neurons and spikes” in the interactive model →

Chapter 3

Where neurons meet

A spark becomes a chemical, crosses a gap, and becomes a spark again.

Neurons don’t quite touch. Where an axon terminal meets the next cell there is a gap about 20 nanometres wide, the synaptic cleft. The whole junction is a synapse. Estimates put about 100 trillion of them in your brain, though the true number is uncertain by a factor of several.

When a spike arrives, calcium (Ca²⁺) gates open and calcium rushes in. That makes tiny bubbles, vesicles, fuse with the membrane and spill neurotransmitter into the gap. The molecules drift across in well under a millisecond and fit into receptors on the other side, which open to let ions through.

Glutamate is the main “go” signal: it lets Na⁺ in and nudges the next cell towards threshold (an EPSP). GABA is the main “stop” signal: it lets Cl⁻ in and holds the cell back (an IPSP). One synapse gives well under 1 mV, so the receiving neuron fires only when many inputs add up, arriving together (spatial summation) or in quick succession (temporal summation).

Learning changes synapses. When one cell repeatedly helps fire another, their synapse gets stronger, often by adding receptors. This long-term potentiation (LTP) is summed up as “cells that fire together wire together”. Many drugs act here too: caffeine blocks receptors for adenosine, a chemical that builds up and makes you sleepy; nicotine mimics acetylcholine; many antidepressants slow the clean-up of serotonin; alcohol boosts GABA’s braking effect. These are facts, not advice: medicines are for a doctor to decide.

Try “Synapses” in the interactive model →

Chapter 4

Who does what

Areas with jobs, a body map with giant hands, and no silent 90%.

Different patches of cortex have different main jobs. At the back, the visual cortex in the occipital lobe handles what you see (see EyeClear). On top of the temporal lobe, the auditory cortex handles sound (see EarClear). The prefrontal cortex behind your forehead plans, decides and holds back impulses. The cerebellum smooths every movement, and the hippocampus helps you remember.

Just in front of the central sulcus runs the motor strip, which moves the body, and just behind it the touch strip. Each has a map of the body, the homunculus (“little man”). Hands, lips and tongue get huge areas because they are so skilled and sensitive. The maps are crossed: your left hemisphere moves and feels your right side.

In most people, language leans left: Broca’s area helps produce speech and Wernicke’s area helps understand it. But “left-brained” logical and “right-brained” creative personalities are a myth. A 2013 study of over 1,000 brain scans found no sign of people being more left- or right-brained overall. Both halves work together all the time.

And the “we only use 10% of our brain” myth? Also false. Brain scans show activity all over the brain, and over a day every region gets busy. Damage to almost any small area causes problems. The brain is far too hungry for energy to carry 90% dead weight. Real scans, like fMRI (see MRIClear), show the extra activity a task adds on top of a brain that is always working.

Try “Who does what” in the interactive model →

Chapter 5

How memories are made

A seahorse-shaped sorter by day, a replay machine by night.

Short-term memory holds only a handful of things, about four to seven, for seconds, like a phone number you are about to dial. Long-term memory can last a lifetime. Getting from one to the other depends on the hippocampus, a curved strip deep in each temporal lobe.

We know this partly thanks to one man. In 1953, Henry Molaison, known for decades only as “H.M.”, had surgery to treat severe epilepsy. Surgeons removed much of both hippocampi. His seizures eased, but he could no longer form new long-term memories of events and facts. He could still chat, remember his childhood and even learn new skills, such as drawing in a mirror, without remembering the lessons. The psychologist Brenda Milner and others studied him with his cooperation for over 50 years. His case showed that memory has separate systems, and that the hippocampus is key to making new ones.

Much of this work happens while you sleep. A night runs in cycles of about 90 minutes: light N1 and N2, deep slow-wave N3, then dreaming REM sleep. Deep sleep comes mostly early in the night and REM mostly late. During N3 and the sleep spindles of N2, the hippocampus replays the day and the cortex files it away. That is why a good night’s sleep after studying helps you remember.

Try “Memory and sleep” in the interactive model →

Chapter 6

Fuel, flow and what goes wrong

A hungry organ, a guarded supply line, and why minutes matter.

Your brain is about 2% of your body weight but uses about 20% of its energy at rest, roughly 20 watts, like a dim light bulb (see EnergyClear). It burns mostly glucose and oxygen, delivered by about 750 mL of blood a minute. It stores almost none, so even a few minutes without blood flow causes damage.

Brain blood vessels are lined with tightly sealed cells, the blood–brain barrier. It lets in oxygen, glucose and a few other things and keeps out most germs and toxins, which also makes many medicines hard to get into the brain.

A stroke happens when an artery to the brain is blocked by a clot (most strokes) or bursts and bleeds. The cells it feeds start dying within minutes: in a typical large stroke, about 1.9 million neurons a minute. So doctors say “time is brain”. Learn BE FAST: Balance, Eyes, Face, Arms, Speech, Time. If you see these signs, call emergency services straight away. Treatments that dissolve or remove a clot work best in the first hours.

A hard knock can shake the brain against the skull: a concussion. Headaches, confusion or memory gaps after a knock need a doctor’s check. Helmets spread the stop over a longer distance, cutting the force (see MotorcycleClear).

The brain keeps rewiring all your life: neuroplasticity. After an injury, other areas can sometimes take over lost jobs with practice. Dementia, most often Alzheimer’s disease, slowly damages memory and thinking, mostly in older age. Sleep, physical activity, not smoking, and treating high blood pressure are linked with healthier brains. This box gives general facts only: for any worry about your own health, see a doctor.

Try “Keeping it healthy” in the interactive model →

Test yourself

Frequently asked

Which lobe is mainly for vision?

Occipital. The occipital lobe at the back of the head holds the visual cortex, where signals from the eyes arrive.

How thick is the grey-matter cortex?

About 2–4 mm. The cortex is a thin sheet, only millimetres thick. Folding into gyri and sulci packs a large area into the skull.

What does the corpus callosum do?

Links the left and right hemispheres. It is a bridge of about 200 million nerve fibres that lets the two halves share information.

What happens if the input only pushes a neuron to −60 mV?

Nothing: it is below the −55 mV threshold. Spikes are all-or-nothing. Below threshold there is no spike at all.

How does a neuron signal a stronger stimulus?

Fires spikes more often. Every spike is the same size, so strength is coded in how often it fires: rate coding.

Why does myelin speed up signals?

The spike jumps between gaps in it, the nodes of Ranvier. Insulated stretches carry the charge quickly and the spike is only rebuilt at the nodes: saltatory conduction, up to about 120 m/s.

What makes vesicles release neurotransmitter?

Calcium rushing into the terminal. The arriving spike opens calcium channels, and Ca²⁺ triggers the vesicles to fuse and spill their contents.

Why does a neuron usually need many inputs to fire?

Each synapse gives well under 1 mV, but threshold is about 15 mV above rest. Many small EPSPs must add up, together in space or quickly in time, to reach threshold.

What does “cells that fire together wire together” describe?

Synapses getting stronger when used together (LTP). When one cell repeatedly helps fire another, their synapse strengthens: a cellular basis of learning.

Which hemisphere mainly moves your right hand?

The left. Movement and touch are crossed: the left motor strip controls the right side of the body.

Why are the homunculus’s hands and lips so big?

They have the most brain area, for fine control and touch. Each body part is drawn as big as its patch of cortex. Hands, lips and tongue are the most skilled and sensitive.

Do we only use 10% of our brain?

No: scans show activity all over the brain, and every area has jobs. It is a myth. Over a day every region is active, and damage to almost any area causes problems.

What happened to H.M. after his hippocampi were removed?

He could not form new long-term memories of events. His old memories and skills stayed, but new events and facts faded within minutes. It showed the hippocampus is key for making new memories.

How long is one sleep cycle, roughly?

90 minutes. A night has about four to six cycles of roughly 90 minutes, each passing through light, deep and REM sleep.

When is most deep (N3) sleep?

Early in the night. Deep slow-wave sleep dominates the first cycles; REM grows longer towards morning.

About how much of the body’s energy does the brain use at rest?

20%. About 20%, although it is only about 2% of body weight: roughly 20 W.

What does the T in BE FAST mean?

Time: call emergency services at once. In a stroke, brain cells die by the minute, so getting emergency help fast matters most.

How does a helmet reduce the force of a hit?

Its foam crushes, stretching out the stopping distance. Deceleration is v²/2d: a longer stopping distance d means a smaller peak force on the brain.

Words worth knowing

Neuron
A nerve cell that receives signals on its dendrites and sends spikes along its axon. The brain has about 86 billion.
Action potential
A spike: a brief, all-or-nothing flip of a neuron's voltage from about −70 mV to about +35 mV.
Myelin
Fatty insulation around many axons that makes spikes jump between gaps, the nodes of Ranvier, much faster.
Synapse
The junction where one neuron passes a signal to another, usually by releasing a neurotransmitter.
Neurotransmitter
A chemical messenger such as glutamate (go), GABA (stop), dopamine or serotonin.
Cortex
The folded outer 2 to 4 mm of grey matter, where most thinking, sensing and planning happens.
Hippocampus
A curved structure deep in each temporal lobe that is key to forming new memories.
Neuroplasticity
The brain's ability to change its connections with learning, practice and recovery.
Stroke
Brain damage from a blocked or burst artery. Warning signs: BE FAST.
